Tsheb nqa hauv chaw nres tsheb
Khoom Paub meej
Raws li lub tswv yim ntawm "enlightened by technology, profession guarantees kev nyab xeeb" ntawm WEBSTAR, lub Webstar Tsheb Lift Nyob rau hauv lub chaw nres tsheb integrates advanced traction systems thiab ruaj khov qauv tsim. Kev nyab xeeb yog lub hauv paus tseem ceeb tshaj plaws ntawm WEBSTAR. Lub Webstar Tsheb Nqa Hauv Chaw Nres Tsheb yog tsim tshwj xeeb rau kev siv hauv tsev, muab cov neeg siv - kev paub zoo rau txhua tus neeg siv, thiab tau nruab nrog ntau lub tshuab tiv thaiv npog cov tshuab, hluav taws xob, thiab cov qauv. Cov hmoov-coated steel qauv ntawm Webstar Tsheb Lift Hauv Chaw Nres Tsheb yog xeb- pov thawj thiab corrosion- tiv taus, muaj peev xwm tiv taus ya raws thiab niaj hnub hnav thiab tsim kua muag. Lub tsheb of elevator no tsis tsuas yog tiv thaiv lub tsheb los ntawm khawb, raug tshav ntuj, thiab nag los nag, tab sis kuj coj kev yooj yim thiab kev thaj yeeb ntawm lub siab rau tsev neeg lub neej.
Nws tsis yog ib qho chaw nres tsheb xwb. Lub tsev tsheb of elevator ntawm WEBSTAR embodies lub hom phiaj lub tswv yim ntawm "nce rau lub neej zoo siab". Nws seamlessly integrates rau hauv lub neej txhua hnub thiab, ua tsaug rau German technology thiab nruj zoo tswj, lub elevator no yog qhov zoo tshaj plaws kev xaiv rau cov neeg uas xav kom optimize qhov chaw, txhim khu kev ruaj ntseg thiab txhim khu kev qha chaw nres tsheb. Nrog WEBSTAR, txhua lub caij hauv of the elevator showcases the charm of safe and smart living living.
|
Webstar tsheb of elevator |
|
|
Tshuab chav |
mr/mrl |
|
Ceev |
0.5m/s |
|
Load peev |
3000-12000kg |
|
Mus ncig qhov siab |
3.2-80m |
|
Tsav hom |
vvvf ua |
|
Tswj qhov system |
huab tais |
|
Traction tshuab |
gearless |
|
Cabin loj |
raws li ncej loj |
Tshuab Hom
|
lub ntsiab spec |
load peev (kg) |
3000 |
5000 |
|
|
Rated ceev (m / s) |
0.5 |
0.5 |
||
|
cabin loj (mm) |
dav |
2500 |
3000 |
|
|
qhov tob |
6000 |
7000 |
||
|
qhov siab |
2200 |
2400 |
||
|
Qhov rooj qhib qhov loj (mm) |
dav |
2500 |
3000 |
|
|
qhov siab |
2100 |
2100 |
||
|
hom |
CO 4 panels |
CO 4 panels |
||
|
ncej loj (mm) |
dav |
4300 |
4900 |
|
|
qhov tob |
6500 |
7500 |
||
|
counterweight txoj hauj lwm |
sab laug |
sab laug |
||
|
max taug kev qhov siab (m) |
25 |
25 |
||
|
qhov tob (mm) |
1600 |
1600 |
||
|
overhead qhov siab |
4800 |
4800 |
||
|
tshuab chav siab |
2500 |
2500 |
||
|
hlua |
4 |
4 |
||
Tshuab Roomless Hom
|
lub ntsiab spec |
load peev (kg) |
3000 |
5000 |
|
|
Rated ceev (m / s) |
0.5 |
0.5 |
||
|
cabin loj (mm) |
dav |
2500 |
3000 |
|
|
qhov tob |
6000 |
7000 |
||
|
qhov siab |
2200 |
2400 |
||
|
Qhov rooj qhib qhov loj (mm) |
dav |
2500 |
3000 |
|
|
qhov siab |
2100 |
2100 |
||
|
hom |
CO 4 panels |
CO 4 panels |
||
|
ncej loj (mm) |
dav |
4500 |
5000 |
|
|
qhov tob |
6500 |
7500 |
||
|
counterweight txoj hauj lwm |
sab laug |
sab laug |
||
|
max taug kev qhov siab (m) |
25 |
25 |
||
|
qhov tob (mm) |
1600 |
1600 |
||
|
overhead qhov siab |
5100 |
5800 |
||
|
tshuab chav siab |
/ |
/ |
||
|
hlua |
4 |
4 |
||
